Ingenico iCT250 configuration
Moneris payments are an integrated card payment provider. They're fast, secure, and easy to use.
Moneris payments run via Ingenico payment terminals.
They:
- Are available to Canadian retailers.
- Accept all major credit and debit cards.
- Support Apple Pay and tap payments.
Who can use Moneris Payments
Moneris payments are available to Canadian retailers using:
- Vend Register iPad App
- Ingenico iCT250 payment terminal
Set up each terminal
Connect the Ingenico iCT250 terminal
- Make sure the terminal is connected to power and to your network with an Ethernet cable.
- Make sure that once powered on; the Ethernet logo is green.
- Make sure your paper roll is loaded correctly.
Configure the Ethernet settings first
For each of these steps a period can be entered by pressing the '0' key followed by the '#' key and input is saved/confirmed by pressing the green button.
- Enter ##08 and select 'COMMS TYPE', select 'ETHERNET' and save the settings with the green button, once you see 'TCP CONNECTION OK' press the red button to get back to the home screen.
- Print the configuration of the terminal by entering ##16 from the main screen, enter 'NO' when prompted about trailer messages.
- Take note of the 'ETHERNET PARAMS' section, if it says type is 'STATIC' then skip to the Semi-integrated steps below. Keep this slip for setting up the register later.
- Enter ##13 then select ’TERMINAL SETUP’, then 'TERMINAL TYPE' and choose ’STATIC’.
- Select 'TERMINAL ADDR' next and enter the same address as was printed on your configuration slip.
- Select 'MASK ID' next and enter the same address as was printed on your configuration slip.
- Select 'GATEWAY' next and enter the same address as was printed on your configuration slip.
- Press the red key to step back one menu, then select 'DNS SETUP'.
- Select 'PRIM ADDRESS' next and enter the same address as was printed on your configuration slip.
- Select 'SEC ADDRESS' next and enter the same address as was printed on your configuration slip.
- Once you are done press the red key until you get back to the main screen, the terminal will now reboot.
